Male To Female L Type IP68 2P / 3P 20A Waterproof Connectors

Male To Female L Type IP68 2P / 3P 20A Waterproof Connectors
Male To Female L Type IP68 2P / 3P 20A Waterproof Connectors Male To Female L Type IP68 2P / 3P 20A Waterproof Connectors Male To Female L Type IP68 2P / 3P 20A Waterproof Connectors

Large Image :  Male To Female L Type IP68 2P / 3P 20A Waterproof Connectors

Product Details:

Place of Origin: China
Brand Name: Bett
Certification: CCC,CE,ROHS,UL
Model Number: L20

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Standard export carton
Delivery Time: 37work days
Payment Terms: T/T, Western Union,Paypal, L/C
Supply Ability: 100000sets/eek
Detailed Product Description
Product Name: Big L Type Connector Material: Nylon
Certificate: CE/ROHS/REACH/UL Type: Screw Connector
IP Rating: IP67/68 Voltage: 300V
High Light:

3P 20A Waterproof Connector

,

L Type Waterproof Connector

,

Male To Female 20A Waterproof Connector

    L Type IP68 2P/3P 20A Waterproof Connector 300V Male to Female Connector



Detailed Product Description

Protection Level: IP68 Connecting Model: Screw Locking
Pin: 2 to 4pin      Current Rating: 20A
Model: L20 Voltage Rating: 300V




Description of 4Pole Connector



Screw locking waterproof connector is a great choice for your application, thanks to its thread locking structure, the protection level could meet IP68. If you are looking for IP68 waterproof connectors, screw locking L20 connectors will be a perfet option. it is widely used in many application.



Operation Parameters
Voltage Rating 300VAC max
Current Rating 20A max
Min Wire Size OD 3.0mm ~ 7.5mm
Max Wire Size OD 7.5mm ~ 18mm
Max.Cable Cross Section Area 0.3mm2 ~ 2.5mm2



Features:

  • Rated current: 20A/10rms.
  • 2-4PIN power supply
  • IP67/68 rating
  • Voltage rating: 300V
  • Cable Range: 3~11mm
  • UL, TUV, CB, CCC, CE, RoHS approved


Main characteristics

  • Sealed against dust and fluid (IP68)
  • Vibration resistance,impact resistance,stretching resistance
  • socket with cover
  • Cable assembly support
  • Customized cable size and length



Applicaiton of Bett L20 Connectors

  • Communications Application
  • product coding machines
  • inventory product coding
  • inkjet systems
  • Solar System
  • industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic&pathology equipment
  • Communications equipment
  • Heavy machinery


FAQ



1. Q: What type waterproof connector do you have?


A: We have 17series type connector,and make more than 3000types waterproof connector cable.Most of our connector is customized.We foucs on LED Waterproof connector,Assembly waterproof connector,Over-mold waterproof connector,T waterproof connector,Y customized waterproof connector.



2Q:Is the sample avaliable and free?

A: sample is available, but it should be paid in advance. The cost of sample will be refunded after further order.



3Q: Can you assured the quality?

A: Yes, weve gained the CE, RoHS, ip65-ip68, UL certification. And weve have strict QC team, all products will be tested before delivery.



4Q: Whats the terms of payment?

A: We can accept T/T, LC, Paypal and Western Union



5Q: Whats the delivery time?

A: It depends on the quantity, as usual it will takes 3-5 for small quantity.





Product description

Product name L20
Product type straight angle,right angle,t-type three way waterproof plugs,avitation plugs,etc.
Material all materials are compliant with RoHS
MOQ small quantity can be accepted
Product length can be customized
Color can be customized
Application

Fast connection of optoelectronic technology products,outdoor light strips,urban lighting projects,solar light srings,lighting appliances,electromechanical equipment,equipment controllers,etc.

Payment term 30% deposit,70%before shipment,100%T/T,or by Paypal
Service OEM or ODM;we accept customization according to your requirement
Delivery time Product quantity ensure delivery time
Product display
