ROHS UL 2 Pin 4 Pin M15 Waterproof Circular Connector

Brand Name:	Bett
Model Number:	M15
MOQ:	Negotiable
Price:	Negotiable
Delivery Time:	3-7 work days
Payment Terms:	T/T,Western Union,Paypal,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,CCC,ROHS,UL

Material:

Nylon

Certificate:

CE/ROHS/REACH/UL

IP Rating:

IP67/IP68

Maximum OD:

3.5-9.0

Optional Cores:

2 To 4pins

Voltage:

300V

Packaging Details:

Standard export carton

Supply Ability:

100000sets/week

Highlight:

ROHS UL waterproof circular connector

2 pin waterproof circular connector

4 pin M15 circular connector

Product Description

ROHS UL 2 Pin 4 Pin M15 Waterproof Circular Connector

M15 Waterproof Circular Connector 2-4pin UL Connector For Breeding Lighting

Detailed product specifications and features for industrial applications.

Protection Level:	IP68	Connecting Model:	Push Locking
Pin:	2 to 4pin	Current Rating:	20A
Model:	M15	Voltage Rating:	300V

Product Overview

M15 waterproof connector is an excellent choice for demanding applications, featuring a thread locking structure that achieves IP68 protection level. These connectors are widely used across various industrial applications.

Operation Parameters

Voltage Rating	300VAC max
Current Rating	20A max
Min Wire Size OD	3.5mm ~ 5.5mm
Max Wire Size OD	5.5mm ~ 9mm
Max Cable Cross Section Area	0.3mm² ~ 1.5mm²

Key Features

Rated current: 5-20A/10rms
2-4pin power supply, 5-9pin signal optional
IP67/68 rating
Voltage rating: 300V
Cable Range: 3.5-9mm
UL, TUV, CB, CCC, CE, RoHS approved

Main Characteristics

Sealed against dust and fluid (IP68)
Vibration resistance, impact resistance, stretching resistance
Socket with cover
Cable assembly support
Customized cable size and length

Applications

Communications equipment
Product coding machines
Inventory product coding
Inkjet systems
Solar systems
Industrial inkjet equipment
Electric power equipment
Laboratory forensic & pathology equipment
Heavy machinery

Frequently Asked Questions

What type waterproof connector do you have?

We have 17 series type connectors and manufacture more than 3000 types of waterproof connector cables. Most of our connectors are customized. We focus on LED waterproof connectors, assembly waterproof connectors, over-mold waterproof connectors, T waterproof connectors, and Y customized waterproof connectors.

Is the sample available and free?

Samples are available but must be paid in advance. The sample cost will be refunded after further orders.

Can you assure the quality?

Yes, we've gained CE, RoHS, IP65-IP68, and UL certifications. We have a strict QC team, and all products are tested before delivery.

What are the terms of payment?

We accept T/T, LC, Paypal, and Western Union.

What is the delivery time?

It depends on the quantity, typically 3-5 days for small quantities.
